Teilenummer
Entmilitarisierung
Lagerfähigkeit
UOM
NIIN
NSN
Nationale Bestandsnummer:
TXT
Beschreibung:
Valve Spring Retainer Lock
MRC:
Indicates whether or not a ferrous alloy object has been subjected to a process whereby the outer portion is made substantially harder than the inner portion or core.AASG
Casehardening Indicator:
Not casehardened
MRC:
The distance measured in a straight line from the bottom to the top of an item.ABKW
Overall Height:
Between 0.432 inches and 0.442 inches
MRC:
A numeric value that reflects the hardness of a metallic item when used in conjunction with a hardness rating scale.AETC
Metallic Hardness Rating:
241.0 rockwell c and 269.0 rockwell c
MRC:
An indication of whether a portion/s/ of the item is threaded or unthreaded.AFEW
Thread Provision:
Unthreaded
Largest Inside Diameter:
Between 0.310 inches and 0.311 inches
MRC:
The length of a straight line which passes through the center of the largest diameter of an item,and terminates at the outside circumference.AGWM
Largest Outside Diameter:
Between 0.480 inches and 0.482 inches
MRC:
The smallest length of a straight line which passes through the center of an item,and terminates on the inside circumference.BKKZ
Minimum Inside Diameter:
0.251 inches
First Ridge Radius:
Between 0.061 inches and 0.063 inches
Distance From Bottom To First Ridge Center:
0.055 inches
First Ridge Width:
0.109 inches
Outside Included Angle In Deg:
10.0
MRC:
The element,compound,or mixture of which an item is fabricated,excluding any surface treatment.MATL
Material:
Steel
MRC:
The chemical compound or mechanical mixture properties of which the item is fabricated.MATT
Material:
Steel
MRC:
The style designation indicating the configuration that most nearly corresponds to the appearance of the item.STYL
Style Designator:
Straight bore w/one ridge
