Teilenummer 10638847

Steering Tie Rod End

Preise und Verfügbarkeit

Reichen Sie dieses Formular ein, um die aktuellen Preise und die Verfügbarkeit dieser NSN zu erfahren.
Teilenummer:
Menge:
E-Mail-Adresse:
Telefon:
Referenz:
Firma:
Name:

Wir geben Ihre Daten nicht an Dritte weiter und verkaufen sie auch nicht.
Privatsphäre | Bedingungen

All major credit cards accepted as well as gov. p-cards

Historische Preise für dieses Produkt liegen zwischen 224.52 and 303.102 USD. Abhängig von Menge, Verfügbarkeit, Zustand, Lieferzeit und möglicher Einstellung eines Artikels können wir die Preise erst garantieren, wenn wir Ihnen ein aktuelles Angebot unterbreiten.

Teilenummer
Entmilitarisierung
Lagerfähigkeit
UOM
NIIN
Teilenummer:
10638847
Entmilitarisierung:
No
Lagerfähigkeit:
N/A
Maßeinheit:
1 EA
NIIN:
011583196

Informationen zum Teil
Weapon system essential

NSN
Nationale Bestandsnummer:
2530-01-158-3196 2530011583196
TXT
Beschreibung:
Steering Tie Rod End
INC
INC
Artikelname-Code:
15952
MRC:
The direction of the thread when viewed axially. a right-hand thread winds in a clockwise direction while a left-hand thread winds in a counterclockwise direction.AAJF
Thread Direction:
Right-hand
MRC:
A measurement of the longest dimension of the tapered portion of an item,in distinction from width.ABND
Taper Length:
0.830 inches
MRC:
Designates the thread diameter and number of threads per specific measurement scale.ABUJ
Thread Size:
3/4-16
MRC:
A designation distinguishing one group of screw thread diameter-pitch combinations from another by the number of threads per measurement scale for a specific diameter.AJYP
Screw Thread Series Designator:
Unf
MRC:
Indicates the design type of the item.APGF
Design Type:
Ball stud
MRC:
An indication of whether or not a removability feature is included.AQZK
Removability Feature:
Included
MRC:
An indication of whether or not a ball stud is included.CFCD
Ball Stud:
Not included
MRC:
The portion/s/ of the rod connection end on which the thread is located.CFCL
Rod Connecting End Thread Location:
External
MRC:
Designates the thread diameter and number of threads per measurement scale of the rod connecting end.CFCM
Rod Connecting End Thread Size:
11/16-18
MRC:
A designation distinguishing one group of thread diameter-pitch combinations from another by the number of threads per measurement scale for a diameter of the rod connecting end.CFCN
Rod Connecting End Thread Series Designator:
Uns
MRC:
The direction of the rod connecting end thread when viewed axially. a right-hand thread winds in a clockwise direction while a left-hand thread winds in a counterclockwise direction.CFCP
Rod Connecting End Thread Direction:
Right-hand
MRC:
A measurement of the extent of complete (full) threads along a line parallel to the longitudinal axis of the rod connecting end.CFCQ
Rod Connecting End Thread Length:
1.020 inches
MRC:
The master requirement codes of those requirements which are technically critical by reason of tolerance,fit,performance,or other characteristics which affect identification of the item.CRTL
Criticality Code Justification:
Feat
