Teilenummer
Entmilitarisierung
Lagerfähigkeit
UOM
NIIN
Entmilitarisierung:
Yes - DEMIL/MLI
Maßeinheit:
* special requirements. EA
NSN
Nationale Bestandsnummer:
TXT
Beschreibung:
Centrifugal Fan Assembly
MRC:
The number of stages incorporated in the item.AAYD
Stage Quantity:
1
MRC:
A measurement taken at right angles to the length of an item,in distinction from thickness.ABGL
Width:
6.000 inches
MRC:
A measurement of the longest dimension of any object,in distinction from width.ABRY
Length:
4.838 inches
MRC:
The environmental elements or conditions that an item is designed or protected to resist or withstand satisfactorily.ADZC
Environmental Protection:
Fungus resistant
Outlet Inside Width:
0.573 inches
Outlet Inside Height:
1.260 inches
MRC:
The static pressure measured at the air flow rate specified.AJLY
Static Pressure At Specificationified Air Flow Rate:
12.0 inches of water
MRC:
Indicates the type of drive for turning,rotating,or positioning the mechanism.AKCV
Drive Type:
Direct
MRC:
Indicates the type and number of facilities by which the item is mounted.AXHR
Mounting Facility Type And Quantity:
6 base
MRC:
The direction of rotation for which the item is designed.AYSY
Rotation Direction For Which Designed:
Counterclockwise
MRC:
Those features,not otherwise specified,which may be required for proper functioning of the item.CBBL
Features Provided:
Nonsparking
MRC:
The rated capacity of air flow moved through the item.CQKX
Air Flow Rate:
Between 12.0 cubic feet per minute and 20.0 cubic feet per minute
MRC:
Indicates the location of the outlet on the item.CRWJ
Outlet Location:
Bottom
MRC:
The direction in which the item discharges during operation.CXCB
Discharge Direction:
Vertical down
MRC:
A measurement from the bottom to the top of an object,in distinction from depth.HGTH
Height:
5.495 inches
MRC:
The chemical compound or mechanical mixture properties of which the item is fabricated.MATT
Material:
Aluminum alloy
MRC:
The metallic,nonmetallic,and/or chemical properties with which the item is plated,dipped,and/or coated.the treatment is designed to protect the surface(s) and cannot be wiped off.SFTT
Surface Treatment:
Anodize
MRC:
The style designation indicating the configuration that most nearly corresponds to the appearance of the item.STYL
Style Designator:
Fixed, rectangular outlets
