Beschreibung:
Self-aligning Plain Bearing
MRC:
The length of a straight line which passes through the center of a circular bore,and terminates at the circumference.ABXV
Bore Diameter:
Between 0.2495 inches and 0.2500 inches
Outer Member Outside Diameter:
Between 0.6557 inches and 0.6562 inches
Outer Member Width:
Between 0.2450 inches and 0.2550 inches
Inner Member Width:
Between 0.3380 inches and 0.3480 inches
MRC:
The limiting radial load which the item can carry at rest without permanent deformation of the stressed surface or the danger of fracture.AGKP
Static Radial Load Rating:
7500 pounds
MRC:
A numeric value that reflects the hardness of an item when used in conjunction with a hardness rating scale.CQFM
Hardness Rating:
28.0 rockwell c inner member and 58.0 rockwell c inner member
MRC:
A numeric value that reflects the hardness of an item when used in conjunction with a hardness rating scale.CQFM
Hardness Rating:
28.0 rockwell c outer race member and 58.0 rockwell c outer race member
MRC:
The chemical compound or mechanical mixture properties of which the item is fabricated.MATT
Material:
Plastic polytetrafluoroethylene race liner
MRC:
The chemical compound or mechanical mixture properties of which the item is fabricated.MATT
Material:
Steel inner member
MRC:
The chemical compound or mechanical mixture properties of which the item is fabricated.MATT
Material:
Steel outer race member
MRC:
The metallic,nonmetallic,and/or chemical properties with which the item is plated,dipped,and/or coated.the treatment is designed to protect the surface(s) and cannot be wiped off.SFTT
Surface Treatment:
Cadmium inner member
MRC:
The metallic,nonmetallic,and/or chemical properties with which the item is plated,dipped,and/or coated.the treatment is designed to protect the surface(s) and cannot be wiped off.SFTT
Surface Treatment:
Cadmium outer race member
MRC:
The style designation indicating the configuration that most nearly corresponds to the appearance of the item.STYL
Style Designator:
With insert and/or liner
