Informationen zum Teil
Starter, 24vdc engine, diesel
NSN
Nationale Bestandsnummer:
TXT
Beschreibung:
Electrical Engine Starter
MRC:
The length of a straight line which passes through the center of a mounting hole,and terminates at the circumference.ABTB
Mounting Hole Diameter:
0.404 mils and 0.414 centimeters
Mounting Hole Circle Radius:
2.500 inches
MRC:
The style designation indicating the configuration that most nearly corresponds to the shape of the mounting flange.ADMD
Mounting Flange Shape Style:
Triangular
MRC:
The national stock number or the identification information of the end equipment for which the item is a part.AGAV
End Application:
USED-ON-930-16B6
MRC:
A measurement of the longest dimension of an item unencumbered by packaging or packing,in distinction from width.AJAF
Unpackaged Unit Length:
15.600 inches
MRC:
A measurement taken at right angles to the length of an item unencumbered by packaging or packing,in distinction from thickness.AJAG
Unpackaged Unit Width:
5.250 inches
MRC:
A measurement from the bottom to the top of an item unencumbered by packaging or packing,in distinction from depth.AJAH
Unpackaged Unit Height:
8.245 inches
MRC:
The style designation indicating the configuration that most nearly corresponds to the appearance of the engaging mechanism.AKCP
Engaging Mechanism Style:
Peripheral outboard gear drive w/worm shaft, barrel and rubber compression cushion w/drive housing
MRC:
The amount of rotation of the opening in the drive housing from the horizontal plane,in a clockwise direction,necessary to enable the starter pinion to engage the flywheel ring gear,expressed in degrees.AKCQ
Engaging Mechanism Opening Angular Deviation In Deg:
90.0
MRC:
The direction of rotation of a rotating shaft as viewed from the drive end.AKCT
Shaft Rotation Direction:
Clockwise
MRC:
Indicates the type of device that actuates the rotation of the armature.AKCW
Armature Actuation Device Type:
Relay-solenoid
MRC:
The specific engine for which the item is designed.AKDA
Specific Engine Application:
Perkins engines ltd, diesel, model t4.236
Mounting Flange Angular Deviation In Deg:
315.0
MRC:
Those features,not otherwise specified,which may be required for proper functioning of the item.CBBL
Features Provided:
Corrosion resistant and fungus resistant treatment and submersible
MRC:
The total electrical voltage.ELEC
Voltage In Volts:
24.0
MRC:
Those unusual or unique characteristics or qualities of an item not covered in the other requirements and which are determined to be essential for identification.FEAT
Special Features:
Vibration & shock resistant
MRC:
Characteristics or qualities of an item,not covered in any other requirement,which are considered essential information for one or more functions excluding nsn assignment.SUPP
Supplementary Features:
Classified as heavy duty; pinion - 10 teeth on an 11 tooth blank; pitch - 8/10; press. Angle - 20 degrees; maj dia. 1.575; pitch dia. - 1.375; root dia. - 1.125 max. 1.6120/1.6160 over 0.2160 dia. Pins
MRC:
The specification,standard,drawing,or similar instrument that specifies environmental and performance requirements or test conditions under which an item is tested and establishes acceptable limits within which the item must conform identified by an alphabetic and/or numeric reference number. includes the commercial and government entity (cage) code of the entity controlling the instrument.TEST
Test Data Document:
81349-mil-s-3785 specification (includes engineering type bulletins, brochures, etc., that reflect specification type data in specification format; excludes commercial catalogs, industry directories, and similar trade publications, reflecting general type data on certain environmental and performance requirements and test conditions that are shown as "typical", "average", "", etc.).
MRC:
Indicates the type and number of terminals for providing electrical connection.TTQY
Terminal Type And Quantity:
1 threaded stud
MRC:
The document designator of the specification or standard which established the item of supply.ZZZK
Specification Data:
81349-mil-s-3785 government specification
MRC:
The number,letter,or symbol that indicates the type,style,grade,class,and the like,of an item in a nonidentifying specification or standard.ZZZT
Specification Or Standard:
Ii type and a grade and ii class
