Teilenummer
Entmilitarisierung
Lagerfähigkeit
UOM
NIIN
NSN
Nationale Bestandsnummer:
TXT
Beschreibung:
Conductor Splice
MRC:
A measurement of the longest dimension of an item,in distinction from width.AAJU
Overall Length:
2.328 inches
MRC:
The maximum size of the conductor the item is designed to accommodate.AAKV
Maximum Conductor Size Accommodated:
6 awg
MRC:
The feature consisting of sleeves,covering,caps,mounting bushings and the like,used to electrically insulate an item.AALV
Electrical Insulation Feature:
Insulating sleeve
MRC:
The application of color or a series of colors for the expressed purpose of identifying the specific functional design and/or the system application of an item.AAPC
Identification Code Color:
Blue
MRC:
The style designation indicating the configuration that most nearly corresponds to the basic appearance of the item.AGTA
Basic Shape Style:
Crimp
MRC:
Indicates the type of connector or conductor accommodation included on the item.CSFJ
Conductor Accommodation Type:
Recessed barrel all ends
MRC:
The chemical compound or mechanical mixture properties of which the item is fabricated.MATT
Material:
Plastic polyamide
MRC:
The specification,standard,or manufacturers reference,and the classification designation,such as class,condition,temper,and the like,that identifies the material.MDCL
Material Specification:
Mil-m-20693, type i or iii military specification single material response insulation
MRC:
The metallic,nonmetallic,and/or chemical properties with which the item is plated,dipped,and/or coated.the treatment is designed to protect the surface(s) and cannot be wiped off.SFTT
Surface Treatment:
Tin except insulation single layer
